High Temperature Microwave Oven Furnace Microwave Sintering Furnace 150x150x260

GZK-15-20 Microwave sintering furnace is our most advanced research furnace.It offers the entire range of features that come standard with HAMiLab-HV6000, with advanced atmosphere control for air sensitive samples.Materials maybe processed up to 1600 degree Celsius in a vacuum below 10^-3Pa or in nitrogen or inert gases.

1. Compounding and sintering of inorganic powder
1). Carbide: SiC, CrC, VC, etc
2). Nitride: Si3N4, MnxNy, AlN, VN, CrN, etc
3). Electronic ceramic powder: barium titanate, barium-strontium titanate, strontium titanate, barium zirconate titanate, etc.
4). Fluorescent powder (LED powder, three primary colors, long after glowing phosphor powder, etc)
5). Lithium-ion battery material: lithium cobaltoxide, lithium manganate, LiFePO4, etc, anode and cathode carbon materials.
6). Multi colors ceramic pigment, glaze material, ceramic raw material, etc.

2. Inorganic material/products sintering
1). Electronic ceramic: BaTiO3, SrTiO3, ZnO piezoelectric ceramics, PTC thermo-sensitive components, etc.
2). bio medical ceramic: man-made bones, teeth, MgO, Al2O3, ZrO2, SiC, Y2O3, Si3N4, SiO2, etc high performance structure ceramic.
3). Daily-used ceramics, arts and crafts ceramic.
3. Incinerating
4. Melting and thermal treatment
5. Melt oxidized ore carbon thermal reduction

1. Using stepless adjustable, high stability and long lifetime, CW industry level microwave source to make sure that the system can run continuous and stable for long time.
2. Use high accuracy IR thermometer to measure sample temperature directly.
3. Equipped with 2nd level high vacuum machine unit and multi channels gas way, atmosphere in the furnace can be controlled accurately.
4. Equipped with embedded computer control system, provide 3 operation mode: manual, auto and constant temperature which can be free switched.
5. Multi original special crucible can be chosen, material placed in the crucible will not be polluted.
6. Materials with different coupling degree with microwave source can be processed—with high universality.
7. Set anticorrosion exhaust way to exhaust gas produced in the heating process quickly.
8. Real time temperature chart display can dynamic monitor the heating process.
9. Secure and reliable microwave shielding chamber design, multi leakage-proof protection.
